Monitor LCD Screen Wall Mount Touch Hand Sanitizer Dispenser Kiosk
This hand sanitizer is a portable way to kill germs and reduce bacteria on your hands. It has a unique dispensing mechanism more effective than standard lotions or gels, ensuring you get every drop. The touch-free pump allows you to use one hand while your other refills the bottle.
Meet Advertising Display Kiosks Manufacturer
CY Digital Signage is a displays solutions manufacturer over 12 years, committed to China’s high-end displays manufacturing, focusing on OEM ODM capabilities, professional to create your brand.
This handy and practical hand sanitizer dispenser comes with a digital signage window. Because digital signage allows you to display a range of advertisements, messages, videos, news information and other forms of communication, you can display more content in a short amount of time. Plus, you can control the screen content remotely from any computer at any time using cloud-based digital signage software.
The hand sanitizer digital signage system is available in two sizes and two all-in-one styles; wall-mounted or freestanding kiosk. Wall-mounted hand sanitizer digital signage sits flush with the wall and is ideal for locations with limited floor space such as retail stores, nail salons, banks or medical clinics. Freestanding digital hand sanitizer kiosk systems are ideal for high-traffic public spaces such as malls, airports, grocery stores, schools or museums.
Key Features
* Full metal case design for business use
* Android 7.1, RK3288, 1GB RAM, 8GB storage
* Automatic - sensor controlled dispenser for non-contact operation
* Can be filled with a variety of disinfectants - gels, liquids, foams
* Large capacity 1500ML on 21.5 inches
* Easy refill. Light sensor will indicate full/medium/empty status
* Supports WiFi, hardwired or 3/4G network connectivity
* Built-in Android media player
* Touch screen or non-touch screen
* Remote monitoring of usage counts and capacity alarms
* Optional battery power
* Optional different stand
WASH-FREE & KEEP SAFE
Smart advertising machine, can set multi-split screen, the same screen display multiple ads. Support formats pictures, video, music and etc.
| Version | Android WiFi (Non-Touch) | Android WiFi & Capacitive Touch |
| Material | Full Strong metal housing | |
| CPU | RK3288 | |
| RAM | 1GB | |
| Internal memory | 8GB | |
| Operation system | Android 7.1 | |
| CMS | With high-end CMS cloud software &temperature data record and bound to face picture& sanitizer | |
| level detection and dispensing data record(email and browser check) | ||
| Temperature detector | With single-point Passive Temperature Scan Function(10cm-50cm distance, ambient temperature detection 15°-35°) | |
| Camera | With one normal front 2.0MP camera(recording face picture, bound with body temperature) | |
| Floor stand | With sanitizer dispenser red-light alarm sensor to light-on when less than 10%(3 colors LED light: red=less than 10%, green=enough sanitizer, blue=when in using | |
| Dispenser tank capacity | 1500ml | |
| Dispenser nozzle | standard gel nozzle, spray nozzle optional | |
| Touch panel | No | Multi-touch Capacitive Touch Panel |
| Display resolution | 21.5" LCD FHD IPS full view angle screen, 1920*1080 FHD; Ratio: 16:9 LED backlight (30,000 hrs lifetime) | |
| Display brightness | Brightness: 250cdm2; IPS panel View angle: 178/178; Contrast ratio:3000; | |
| WiFi | WiFi 802.11 | |
| 3G/4G | Optional | |
| Ethernet RJ45 | Yes | |
| Bluetooth | Yes, BT4.0 | |
| USB port | Yes (2 x USB ports) | |
| WiFi port | Yes | |
| RJ45 | Yes | |
| On/off switch | Yes | |
| Video format | MPEG-1,MPEG-2,MPEG-4,H.264,H.264,RV etc.,support up to 1080p | |
| Audio format | MP3/WMA/AAC etc. | |
| Photo | JPEG, PNG and etc. | |
| Power consumption | 60W | |
| Operating Temperature | -10°~70° | |
| Dispenser pump/nozzle | Standard with gel pump | |
| Speaker | 2*5W | |
| Language | English & Multi-language | |
| Power supply | AC cable, suitable for worldwide 100V-240V, 50/60Hz | |
| Color | Standard white or black color (optional red/yellow/pink/rose/green,etc.with MOQ 10pcs) | |
| Unit Size | main machine: 117.6x35.7x18.6cm; floor base: 34.1x29.8xcm; metal stand: 115x15cm (support 20cm stretch out); | |
| Packing | box 1(main machine with honeycomb carton): 118x25x45cm, 20 kgs (Volume weight 27kg),0.133CMB | |
| box 2(floor stand with normal paper carton): 119x16x21cm, 5.7 kgs (Volume weight 8.5kg),0.04CBM | ||
| box 3(ground base with normal paper carton): 54x43x8cm, 11 kgs (Volume weight 4kg), 0.019CBM | ||
| Container load quantity | 1.w/o floor stand: 20' 180pcs; 40'GP 406pcs; 40'HQ 511pcs; | |
| 2.include floor stand: 20' 150pcs; 40'GP 330pcs; 40'HQ 390pcs; | ||
| Accessories | AC cable (EU/UK/US/AU plug select-able), WiFi antenna (Android version only), door key, wall mount bracket, user manual; | |
Where To Use
10 Tests Before Leaving The Factory
Screen Test---DC Voltage Test---High Voltage Test---Touch Test---High Temperature Test---Constant Temperature Test---Vibration Test---Drop Test(option)---Static Test---Aging Test
A. Packaged with vacuum bag;
B. Pearl carton dust bag packaging;
C. 15mm thickness pearl cotton protection;
D. 5 layers corrugated carton;
E. Honeycomb cardboard box for device up to 27inch;
F. Automatic machine sealing packing belt protection;
G. Packing method can be negotiated: Fumigation-free wooden case packaging or Flight case packaging.
Pre-Saleservices
A: Provide total solutions according to customer request free of charge.B: Provide local technical support if necessarily.
In-Salesservices
A: Delivery on time.B: Provide structure and installation drawing according to customer request.
C: High efficiency transportation service.
After-Salesservices
A: One year free maintenance, life time maintenance.B: 7*24 hours response time.
C: Provide necessary accessories with products.
D: Free technical training.
E: Regular telephone satisfaction return test.
F: Software upgrade free of charge.
" If you are looking for excellent hardware, ease of use and hands down the best tech support look no further. Highly recommend. ----- Karen Bass Italy
As a full service real estate brokerage specializing in property management services were were confident after doing our research that CY Digital Signage was the clear choice for our in house hand sanitizer kiosks. ----- Timothy H Wong Santiago
Great product, great service. AAA supplier !! ----- Roshe Ksabi London "
To save you from worries, here are some facts you need to know about our displays & kiosks supplies:
Q1: Are you a factory or trading company?
We are a OEM / ODM factory.
Q2: How long is the warranty time for your products?
Our officially promised warranty time is one whole year after delivery at best.
Q3: Do you have any certification?
Our factory have CE, CCC, UL, ROHS, FCC and ISO9001 certificate. If you have other certificate requirements, we also fully support you.
Q4: What's the shipment terms and delivery time of your company?
Well, they depends on the quantity of your order. As you know ,we need time to manufacture the machines. But mostly, the shipment time is 3-8 working days after delivery. For Delivery way, for Sample and Bulk order < 100KG, we will kindly suggest Express and Air freight, when Air freight and Sea shipping for Bulk order >100KG. As for detailed cost, it depends on your final order.
Q5: What brand of screen are you using?
Samsung, LG, BOE and AUO screen are normally used for the digital signage and video walls, while customized screen is also supported.
Q6: I would like to ask you if it's possible to have my logo on the product.
We hope you know that our company CY Digital Signage perfectly support customized logo service. But we also hope you know that it's an extraservice, so a little bit extra service fee is needed.
Q7. What is your terms of packing?
Generally, we pack our goods inneutral with Inner 4CM PE foam & export carton box, also outer export Fumigation-free wooden case packaging and light case are optional. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q8: What is the minimum order?
1 unit is our minimum order.
Q9: What kind of inspection can you provide?
CY Digital Signage goes through multiple tests from raw material purchase to finished product by multiple departments such as QA, QC, and sales representatives to ensure that all sign players are in the best condition before shipping. We also accept inspection from a third party appointed by you.
Q10: When can I get a quote?
We usually quote within 12 hours after we receive your inquiry. If you are very urgent, please contact us via email, Skype or WhatsApp (+86 1592 0054 142).
