Written By Mark Wang On 24th November 2022
LCD video wall as an important security product, to promote the development of the security field has played an important role, as a video surveillance system necessary terminal product, LCD video wall with excellent display performance, high-definition picture quality effect is highly valued by users in various fields. Now we are more common for video wall signal interference for a system analysis and troubleshooting.
1. There is a strong source of interference near the system
This can be judged through investigation and understanding. If this is the reason, the solution is to strengthen the shielding of the camera, as well as the video cable pipeline grounding treatment.
2. The quality of the video transmission line is not good
Especially poor shielding performance (shielding network is not a very good quality copper wire network, or shielding network is too thin and does not play a shielding role). At the same time, the line resistance of such video lines is too large, thus causing greater attenuation of the signal is also a cause of aggravation of the failure. In addition, the characteristic impedance of this type of video cable is not 75Ω and parameters beyond the specified is also one of the reasons for the failure.
3. Due to the core of the video cable line and shielding network short circuit, breakage caused by the failure
The manifestation of this fault is in the form of deeper and more chaotic large-area mesh interference on the monitor, so that the image is all destroyed, the shape of the image and synchronization signal. This situation mostly occurs in the BNC connector or other types of video connectors. That is, when this failure phenomenon, LCD video wall is often not the whole system of the signal of each road are out of the problem, but only in those joints bad road. As long as these joints are carefully checked one by one, you can solve.
4. Caused by the power supply system power supply
In the normal power supply on the iteration of the interference signal. And this power supply on the interference signal, mostly from this grid using silicon-controlled equipment. Especially high current, high voltage silicon-controlled equipment, the pollution of the grid is very serious, which leads to the same power supply in the grid is not "clean". For example, this grid has high-powered silicon-controlled frequency regulation device, silicon-controlled rectification device, silicon-controlled AC-DC conversion device, etc., will produce pollution of the power supply. The solution to this situation is relatively simple, as long as the entire system of LCD video wall using purified power supply or online UPS power supply can basically be solved.
5. The space radiation interference introduced by the transmission line
This interference phenomenon, mostly because of the transmission system, the front end of the system or the central control room near a strong, high frequency space radiation source. The solution to this situation is a system set up, should be aware of the surrounding environment, try to avoid or away from the radiation source; another way is when the radiation source cannot be avoided front-end and center equipment to strengthen the shielding, the transmission line pipeline using steel pipe and good grounding.
6. Due to the transmission line characteristics of impedance mismatch caused by the failure phenomenon
This phenomenon is manifested in the form of a number of equally spaced vertical interference on the monitor screen, the frequency of the interference signal is basically an integer multiple of the line frequency. It can also be said that this interference phenomenon is caused by the LCD video wall system video cable characteristic impedance and distribution parameters are not in line with the requirements of the integrated. The solution generally relies on the "Beginning Of The Series Resistor" or "Terminal and Connected Resistance" method to solve.
