How To Install The Wall-Mounted Advertising Machine? What Are The Precautions?
3/15/2023
Written By Mark Wang On 15th March 2023
If you often go to places with a lot of traffic, you will find more and more advertising machines in our lives, and the emergence of wall-mounted advertising machine to bring benefits to businesses, then how to install wall-mounted advertising machine? What are the precautions? CY Digital Signage advertising machine manufacturers to give you an introduction.
The installation method of wall-mounted advertising machine:
1. Open the box and take out the machine
2. Non-standard wall-mounted board, use the key to open the lock bar, remove the machine anti-theft screws (Note: it is recommended to use a magnetic screwdriver, so as not to anti-theft screws fall in the machine)
3. Remove the machine wall plate (Note: the pegboard removed)
4. Determine the pegboard installation position (to determine the location is recommended to use a level ruler to confirm whether the pegboard remains in the horizontal position)
5. Draw positioning holes (determine the location, draw a good positioning holes in the location of the pegboard)
6. Punching holes (use impact drill to punch holes to fix expansion screws)
7.Wall plate fixed in the installation of the wall (pay attention to the material of the wall, choose different screws for fixing)
8. Connect the power supply, hang the machine, switch the button to light up the machine
Installation of wall-mounted advertising machine precautions:
1. Installation of the wall should be firm
The installation of wall-mounted advertising machine has strict requirements for the solidity of the wall, the user should examine the cement structure of the house before buying a wall-mounted advertising machine.
Must be installed in solid brick, concrete and other high strength walls wall-mounted advertising machine, if it is to be installed in wood or surface decoration layer too thick wall, must first take reinforcement, support measures.
We have to understand that the bearing capacity of the installation surface should be guaranteed to be no less than 4 times the actual load capacity of the digital signage, and the advertising machine should not tip over when it is tilted 10° before and after installation.
2. The environment should not be wet
Wall-mounted advertising machine should not be placed in a humid environment for a long time, as many TVs are not waterproof, so that the digital signage installation location is too close to the moisture will damage the TV.
Should try to avoid strong electricity and the impact of strong electromagnetic field objects, such as electromagnetic appliances, cell phones and other appliances that can be moved at will should be as far away from the TV as possible, and other large appliances should not be placed near the advertising machine.
3. The bracket should be well chosen
Choose a suitable wall-mounted advertising machine bracket is very important, first of all, figure out the classification of the bracket, the current market bracket is mainly divided into adjustable angle hangers and fixed angle hangers.
Digital signage wall bracket should ensure that the digital signage machine after the installation of maintenance, repair convenience, without damaging the mounting surface, the premise of the mounting frame, easy to disassemble.
When buying a wall mount bracket, be sure to check if the mounting bracket includes the wall connection part, product connection part, fastener part, installation schematic and operation instructions, and it should comply with the international VESA organization FDMI standard.
In summary is the introduction of wall-mounted advertising machine installation and precautions, CY Digital Signage focus on LCD advertising machine, touch screen all-in-one machine and other intelligent LCD display terminal equipment solutions manufacturers, to understand more intelligent display advertising machine equipment please feel free to contact CY Digital Signage advertising machine manufacturers.
Mark Wang
Mark Wang is the Chief Technology Officer at CY Digital Signage. And he has over 15 years experiences in digital signage solutions.
